TECHNICAL DATA
| Dimensions (L x W x H) | mm | 700 x 417 x 340 |
|---|---|---|
| Rated voltage | 220 – 240 V / 50/60 Hz | |
| Power consumption | W | 180 |
| Power cable length | m | 7.00 |
| Net weight | kg | 16.70 |
| Guarantee * | Years | 2 |
| UVC power | W | 180 |
| UVC operating hours meter | No | |
| Function check | Visual | |
| Number of inlets | Units | 1 |
| Inlet connections | DN 110 | |
| Number of outlets | Units | 1 |
| Outlet connections | DN 110 | |
| Max. flow rate | l/h | 100000 |
| Max. operating pressure | bar | 0.6 |
| Rec. flow rate (gravity-fed) | l/h | 50000 |
| Suitable for ponds up to max. | m³ | 280.0 |
| Suitable for ponds with fish stock | m³ | 160.0 |
| Suitable for ponds with koi *1 | m³ | 100.0 |
| Material | Plastic / stainless steel | |
| Connection to | AquaMax, ProfiClear | |
| Type of use | Gravity fed system, Pump fed system |
