TECHNICAL DATA
| Dimensions (L x W x H) | mm | 725 x 227 x 248 |
|---|---|---|
| Rated voltage | 220 – 240 V / 50/60 Hz | |
| Power consumption | W | 120 |
| Power cable length | m | 5.00 |
| Net weight | kg | 7.75 |
| Guarantee (+ request guarantee) * | Years | 2 + 1 |
| UVC power | W | 120 |
| Temperature display | Digital | |
| Bypass control | automatic | |
| UVC operating hours meter | 12000 h | |
| Function check | LED | |
| Number of inlets | Units | 1 |
| Inlet connections | mm | 38 / 50 |
| Inlet connections | 1 ½”, 2″ | |
| Number of outlets | Units | 1 |
| Connections, outlet | mm | 38 / 50 |
| Outlet connections | 1 ½”, 2″ | |
| Min. flow rate | l/h | 10000 |
| Max. flow rate | l/h | 50000 |
| Max. operating pressure | bar | 1 |
| Suitable for ponds up to max. | m³ | 120.0 |
| Suitable for ponds with fish stock | m³ | 60.0 |
| Suitable for ponds with koi *1 | m³ | 30.0 |
| Connection to | BioTec 30, BioTec ScreenMatic² 90 – 140000, ProfiClear |
