TECHNICAL DATA
| Dimensions (L x W x H) | mm | 600 x 180 x 198 |
|---|---|---|
| Rated voltage | 220 – 240 V / 50/60 Hz | |
| Power consumption | W | 36 |
| Power cable length | m | 5.00 |
| Net weight | kg | 3.97 |
| Guarantee * | Years | 2 |
| UVC power | W | 36 |
| Temperature display | No | |
| Bypass control | manually | |
| UVC operating hours meter | No | |
| Function check | Visual | |
| Number of inlets | Units | 1 |
| Inlet connections | mm | 19 / 25 / 32 / 38 / 50 |
| Inlet connections | ¾”, 1″, 1 ¼”, 1 ½”, 2″ | |
| Number of outlets | Units | 2 |
| Connections, outlet | mm | 25 / 32 / 38 |
| Outlet connections | 1″, 1 ¼”, 1 ½” | |
| Min. flow rate | l/h | 8000 |
| Max. flow rate | l/h | 30000 |
| Max. operating pressure | bar | 0.5 |
| Suitable for ponds up to max. | m³ | 40.0 |
| Suitable for ponds with fish stock | m³ | 20.0 |
| Suitable for ponds with koi *1 | m³ | 10.0 |
| Connection to | BioSmart 18000/36000, BioTec ScreenMatic² 40 – 60000 |
