TECHNICAL DATA
| Dimensions (L x W x H) | mm | 380 x 360 x 205 |
|---|---|---|
| Rated voltage | 220 – 240 V / 50/60 Hz | |
| Power consumption | W | 20 – 198 |
| Power cable length | m | 10.00 |
| Net weight | kg | 11.00 |
| Guarantee (+ request guarantee) * | Years | 3 + 2 |
| Max. flow rate | l/min | 333 |
| Max. flow rate | l/h | 20000 |
| Max. head height, metres | m | 4.50 |
| Pressure-side connection | mm | 50 |
| Pressure-side connection | 2″ | |
| Suction-side connection | mm | 50 |
| Suction-side connection | 2″ | |
| Hose connection | mm | 25 / 32 / 38 / 50 |
| Hose connection | 1″, 1 ¼”, 1 ½”, 2″ | |
| Filter intake surface | cm² | 1300 |
| Max. coarse debris displacement | mm | 11 |
| Electronic adjustment | Yes | |
| Setup type | Underwater installation only |
