TECHNICAL DATA
| Dimensions (L x W x H) | mm | 275 x 175 x 200 |
|---|---|---|
| Rated voltage | 220 – 240 V / 50/60 Hz | |
| Power consumption | W | 35 – 170 |
| Power cable length | m | 10.00 |
| Net weight | kg | 9.20 |
| Guarantee (+ request guarantee) * | Years | 3 + 2 |
| Max. flow rate | l/min | 525 |
| Max. flow rate | l/h | 31500 |
| Max. head height, metres | m | 3.30 |
| Pressure-side connection | mm | 75 |
| Pressure-side connection | G 2 ½” | |
| Suction-side connection | mm | 75 |
| Suction-side connection | G 2 ½” | |
| Max. coarse debris displacement | mm | 6 |
| Connection EGC | Yes | |
| Electronic adjustment | Yes | |
| Setup type | Can be set up underwater & dry installed |
