TECHNICAL DATA
| Dimensions (L x W x H) | mm | 490 x 240 x 210 |
|---|---|---|
| Rated voltage | 220 – 240 V / 50/60 Hz | |
| Power consumption | W | 60 – 440 |
| Power cable length | m | 10.00 |
| Net weight | kg | 12.00 |
| Guarantee (+ request guarantee) * | Years | 3 + 2 |
| Max. flow rate | l/min | 433 |
| Max. flow rate | l/h | 26000 |
| Max. head height, metres | m | 8.50 |
| Pressure-side connection | mm | 50 |
| Pressure-side connection | 2″ | |
| Suction-side connection | mm | 50 |
| Suction-side connection | 2″ | |
| Hose connection | mm | 38 / 50 |
| Hose connection | 1 ½”, 2″ | |
| Filter intake surface | cm² | 1060 |
| Max. coarse debris displacement | mm | 11 |
| Connection EGC | Yes | |
| Electronic adjustment | Yes | |
| Setup type | Can be set up underwater & dry installed |
