TECHNICAL DATA
| Dimensions (L x W x H) | mm | 280 x 230 x 140 |
|---|---|---|
| Rated voltage | 220 – 240 V / 50/60 Hz | |
| Power consumption | W | 26 – 120 |
| Cable length | m | 2.00 + 10.00 |
| Net weight | kg | 6.50 |
| Guarantee (+ request guarantee) * | Years | 3 + 2 |
| Max. flow rate | l/min | 200 |
| Max. flow rate | l/h | 12000 |
| Max. head height, metres | m | 4.70 |
| Pressure-side connection | mm | 50 |
| Pressure-side connection | 2″ | |
| Suction-side connection | mm | 38 |
| Suction-side connection | 1 ½” | |
| Hose connection | mm | 25 / 32 / 38 |
| Hose connection | 1″, 1 ¼”, 1 ½” | |
| Filter intake surface | cm² | 810 |
| Max. coarse debris displacement | mm | 8 |
| Electronic adjustment | Yes | |
| Setup type | Can be set up underwater & dry installed |
